Quincy Compressor QAF Series Carbon Filter

Activated carbon adsorber reducing the contamination level of compressed air to 0.003 PPM by weight.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our experts at 1-866-778-6572. We’re open 8:00 am to 5:00 pm ET.
List Price: ${{ calcListPrice | formatCurrency }}
Starting Price: $214.20
Selected Options: + ${{ calcAdditionalCost | formatCurrency }}
Request pricing below.
${{ calcCost | formatCurrency }} per {{ calcQuantity }} (${{ unitPrice | formatCurrency }} each) per {{ boxQuantity }} (${{ unitPrice | formatCurrency }} each)
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo

View Company Reviews
Highlights...

Features

  • 6 to 10,500 CFM capacity
  • 0.7psi pressure loss
  • 300psi max pressure
  • 1,000 hour lifetime
  • ISO 8573

The Quincy Compressor QAF Series carbon filter removes hydrocarbon vapors and organic orders. The element contains selected activated carbons specifically developed for compressed air purification. The finely ground, activated carbons are imbedded in the binder free, microfiber fleece creating a highly efficient adsorbing surface. The QAF Series is ISO 8573 compliant and will reduce the contamination level of compressed air to 0.003 PPM by weight. Available in capacities from 6 to 10,500 CFM, the QAF Series features a push-fit proprietary element, dead-stop head-to-bowl connection to ensure safe closure, and a manual drain.

For optimum performance, 0.003 PPM adsorbers should be installed downstream of an air dryer and polishing coalescer.

Part Number Price Available
QAF 175
Show Configuration
$591.60 12 in stock
QAF 105
Show Configuration
$542.30 7 in stock
QAF 25
Show Configuration
$277.10 7 in stock
QAF 50
Show Configuration
$280.50 7 in stock
QAF 70
Show Configuration
$388.45 5 in stock
QAF 85
Show Configuration
$475.15 2 in stock
QAF 125
Show Configuration
$563.55 1 in stock
QAF 280
Show Configuration
$869.55 1 in stock
QAF 32
Show Configuration
$277.95 1 in stock

Interested in Other Part Numbers?

Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 1 to 2 days". Click here to select options
