Hedland API Oil / Caustic and Corrosive Liquid Flow Meter

Variable area flow meter with T316 Stainless Steel body, piston and cone.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our experts at 1-866-778-6572. We’re open Mon - Fri / 8:00 AM - 5:00 PM EST.
Starting Price: $748.00
Selected Options: + ${{ calcAdditionalCost | formatCurrency }}
Request pricing below.
${{ calcCost | formatCurrency }} per {{ calcQuantity }} (${{ unitPrice | formatCurrency }} each) per {{ boxQuantity }} (${{ unitPrice | formatCurrency }} each)
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo

View Company Reviews
Highlights...

Features

  • Temperature up to 240°F
  • Accuracy ±2% full scale
  • T316 Stainless body, piston, and cone
  • 360° rotatable guard/scale
  • Easy-to-read linear scale
  • Repeatability ±1%

The Hedland API Oil / Caustic and Corrosive Liquid Flow Meter is a variable area flow meter with ranges from 0.1 to 1.0 GPM to 10 to 100 GPM. The meter provides direct readings and can be installed in any position. This rugged meter has a T316 stainless body, piston, and cone. It also features a 360° rotatable guard/scale, good viscosity stability, and is relatively insensitive to shock and vibration. It is rated to handle pressures of up to 6000 PSI (some models), temperatures up to 240°F, and has an accuracy of ±2% full scale.
